Model Number :

Configuration parameters

processor : Compatible with monitor/Android

harddisk: 64G/128G/256G/512G/1T storage

Memory : 4G/8G/16G/32G RAM

graphics card : Integrated graphics

Audio: High-fidelity audio controller

Internet : 1/2 gigabit Ethernet ports, 1 wireless Wi-Fi port

Interface: 4*USB, 1*HDMI , 1*VGA, 2*RS232, 1*Audio output

operating system ： Android

Screen parameters

Screen Size : 15.6 inch

screen ratio: 16:9 (H:V)

Resolution: 1920*1080
Contrast: 1000:1 (Type.) (transmission)

Gray-scale response: 5/11 (Type.) (Tr/Td.)(ms)

Viewing angle: 80/80/70/70 (Type.) (CR≥10)

Dot Pitch： 0.080*0.240mm {84PPI}

Brightness : 350cd/㎡  （Typ.）

Touch Screen parameters

Touch Screen : Original touchscreen

Touch lifespan : ≥50 million times

Touch pressure：45g-250g

Surface hardness:≥6H

Touch Solution : Capacitive Touch

linear error: ＜1.5%

Glass type： chemically strengthened acrylic glass

Other parameters

Shell material: Cold-rolled metal sheet + aluminum alloy

Color: Industrial gray

Installation method: Externally recessed, wall-mounted, desktop, VESA standard support arm

Operating temperature: -20 - 60℃

Storage temperature:-10 - 60℃

Operating current：≤5A

Power consumption： 15W-45W

Interface: DC12V*1/HDMI*1/USB*4/LAN*2/AUDIO*1/COM*2

Warranty:12 months

Upgradeable configuration:

RAM: Upgradeable to 8GB/16GB

Harddisk:Upgradeable to 128GB/256GB/512GB SSD, or 500GB/1TB HDD.

processor ：Upgradeable to i3/i5/i7

Module: It can be equipped with an ID/IC card reader, ID card reader, 1D/2D barcode scanner, infrared/light sensor, built-in speaker, wireless Wi-Fi, 4G full network compatibility module, camera, microphone, Bluetooth, and fingerprint module.

Appearance: Custom colors/silk screen logo

Bracket: Vertical brackets, hanging brackets, and adjustable brackets are available for purchase separately.

Interface: Add COM, USB, Ethernet, and aviation interface
