*Product dimensions (mm): (L) 743.7 * (W) 438.1 * (D) 15.7 (min)mm

* Tempered glass thickness (mm): 2.0mm
* Wall support dimensions (mm): 200*200mm
* Mounting screw specifications: M6*12 4PCS

* LCD Glass Model: LG/CSOT/BOE/AUO
* Driver Voltage: 12V
* Signal Type: LVDS 2K (2ch, 8-bit)
* Backlight Type: ELED
* Display Area (mm): 698.4(H)*392.85(V)
* Display Resolution: 1920*1080
* Aspect Ratio: 16:9
* Display Colors: 16.7M
* Contrast Ratio: 1200:1
* Maximum Brightness: 300cd/m² (Try)
* Response Time: 8ms
* Backlight Uniformity: 75%
* Viewing Angle (H/V): 178°(H)/178°(V)
* Touch technology: Capacitive touch
* Number of touch points: Ten-point touch
*Backlight voltage: 41-48V, (DC)
*Backlight current: 240mA*2(Try)
*Standby power consumption: 24W
* Quantity per carton: 1 pc
* Packaging dimensions: (LxWxH) 825*150*535mm
* Unit weight (G.W.): 10.5KG
* Outer packaging dimensions: (LxWxH) 850*180*580mm
* Total weight (G.W.): 9.5KG/12.5KG

Features

1. Industrial-grade exterior design for high reliability and stability.
2. Side-lit ELED backlight for better brightness uniformity and more delicate and realistic color gamut.
3. Integrated aluminum plate heat dissipation for larger heat dissipation area, lower surface temperature, and worry-free long-term load operation.
4. All-sheet metal structure for robustness, security, anti-theft, and vandalism protection; perfectly matched with profile frame.
5. Aviation-grade aluminum front frame with sandblasting and brushed finish.
6. Ultra-thin four-sided equal-sided front frame, only 15.7mm at its thinnest point.
7. High-transparency tempered glass display, 2mm tempered glass, 22.3mm black silkscreen border.
8. Hundred-ton stamping process for the metal back panel ensures robustness and showcases curved lines.
9. All motherboards and electronic components are manufactured using a standard mounting process for easy production and maintenance.
10. LED light from a listed company. Barr LED strip lifespan 30,000 hours (hrs)
11. Includes internal connection cable, AC socket *1, rocker switch *1, 1.5m power cord *1, WiFi antenna *1
12. Supports Android, Windows, and standalone solutions (optional)
13. Touch method: Capacitive touch (USB driverless)
